Hot Sale High efficiency suitable for marble and granite Infrared bridge cutting machine
Product Description
ZDQJ-400-600-700, adopting PLC system and Human-machine interface, togethering with ultra-high precision rotary encoder positioning and infrared device, with Chinese & English double operation language, using inverter to control left-right feeding,adjusting the speed according to stone material, using hydraulic lifting system which equipted through 4 guide post, also this machine provide the unique side beam protection device, main spare parts adopt imported high-quality materials. Thus the whole machine is featured with high cutting efficiency, high cutting precision, high stability, easy-operation, specially high value granite and big size marble.
Technical Parameter
| Parameter | Unit | ZDQJ-450 | ZDQJ-600 | ZDQJ-800 |
| Blade diameter | mm | 300-450 | 350-600 | 350-800 |
| Max processing size | mm | 3200*2000*100 | 3200*2000*170 | 3200*2000*270 |
| Dimension of worktable | mm | 3200*2000 | 3200*2000 | 3200*2000 |
| Worktable tilting degree | ° | 0-85° | 0-85° | 0-85° |
| Worktable rotation degree | ° | 0-90°/0-360° | 0-90°/0-360° | 0-90°/0-360° |
| Main motor | kw | 15 | 18.5 | 22 |
| Gross motor | kw | 20.5 | 24 | 27.5 |
| Water consumption | m³/h | 3 | 3 | 3 |
| Outline dimension | mm | 5850*4700*2700 | 5850*4700*3000 | 5850*4700*3450 |
| Gross weight | kg | 5500 | 5750 | 6000 |
Xianda Machinery
Fujian Xianda Machinery Co.,Ltd is a leading company for stone cutting machines and tools in China, established in 1985 and covers 20,000m³ area which located in Jinjiang Wuli lndustrial area, nearby the longest and oldest stone bridge in the world, named “Wuli Bridge” and next to biggest stone market in the world- Shuitou.
With more than 34 years’ experience specializing in developing and producing a series of diamond wire saw machine, column processing machine, bridge cutting machine, carving machine, profiling linear machine, baluster machine, etc. We occupied around 80% market in China for column processing machines, and own more than 30 overseas countries users.
Since its foundation in 1985, we keep”Top Technology and Superior Quality”as our standard for all machines and got CE, ISO Quality Gold Award , etc.
“China Recommend Building Manufacture Enterprise”, “3A Enterprise Credit Evalution” , etc for company.And we are always the sponsor for education as our CEO Mr Roy is enthusiastic about the public welfare establishments.
Xianda always keep”Creat the highest value of your stone”as purpose,your visiting and contacting is always welcomed.
