Product Description
ZDKQ-1000 Middle Block Water Jet Stone Cutting Machine For Granite Marble uses PLC system and Human-machine interface, combined with Ultra-high precision rotary encoder to locate, and infrared device, it uses inverter to control left-right feeding. Adjusting the speed according to the stone material. It uses hydraulic lifting system.The key part adopt imported good-quality spare parts. Thus the whole machine is featured with high cutting efficiency, high stability, easy-operating to suit specially shaped stone products, tombstone and curb stone.
Specification
|
Technical Parameter
|
Unit
|
ZDKQ-1000
|
ZDKQ-1200
|
|
Blade diameter range
|
mm
|
Φ500-Φ1000
|
Φ700-Φ1200
|
|
Trolley Size
|
mm
|
3000 x 2000
|
3000 x 2000
|
|
Worktable rotation angle
|
°
|
0,90°
|
0,90°
|
|
Main motor
|
kw
|
30-4P
|
22-6P/30-6P(Optional)
|
|
Gross power
|
kw
|
37
|
29/37(Optional)
|
|
Outline dimension
|
mm
|
6150 x 4800 x 3700
|
6150 x 4800 x 3900
|
|
Gross weight
|
kg
|
≈6700
|
≈7000
|
|
Water consumption
|
m³/h
|
≈3
|
≈3
|
